PRODUCT DATA SHEET
JT1150 / GT1150
POLYURETHANE ADHESIVE
TWO-COMPONENT, SOLVENT-BASED
DESCRIPTION
●High green bonding and good reistance to chemical, heat; fine coating performance.
●Applicable to the composite structure of PET/AL, PET/CU, such as ventilation ducting, AL foil Mylar Tape, etc.
●Products conform to the National food safety standards (GB9685) and regulations of adhesive for food package stipulated by China adhesive industry association.
PHYSICAL PROPERTIES | ||
Type | JT1150(Main agent) | GT1150(Curing agent) |
Composition | -OH | -NCO |
Appearance | light yellow viscous liquid | light yellow viscous liquid |
Solid content (%) | 50±2 | 65±2 |
Viscosity at 25 °C(mPa.s) | 2000±1000 | 800±500 |
Solvent | Ethyl acetate | Ethyl acetate |
Mixing ratio (quality) | 20 | 3 |
Shelf life (Months) | 12 | 12 |
Operation Conditions: To begin with dilution by adding solvent into the Main agent as per required solid content, and mixing the solution entirely. Secondly a good mixture by adding the Curing agent into the solution should be made before it can be used. The Ethyl acetate is the first choice as a solvent. (The water content of ethyl acetate should not exceed 0.03%, and the alcohol content should not exceed 0.02%. )Generally the solid content of the adhesive is to be suggested at 25 to 32%. The solid content and quantity of the adhesive should be defined as per the properties of laminated films, conditions of silicon roller and so on. | ||
REFERENCED DILUTION RATIO(QUALITY RATIO) | |||
Solid content of glue to be required (%) | 35 | 30 | 25 |
Main agent (kg) | 20 | 20 | 20 |
Curing agent (kg) | 3 | 3 | 3 |
Ethyl acetate(kg) | 14.34 | 16.83 | 24.80 |
POT LIFE
●Ensure all well-prepared adhesive solution should be consumed in 8 hours, and the remained adhesive solution should not be used any longer in principle. In case there are a large quantites of the adhesive solution to be remained, it is possible to make use of ethyl acetate or fresh adhesive solution to dilute in multiple times and store in a cool and unopened condition. It can be reused by mixing with the newly prepared adhesive solution in a small quantities, but a calculation of mixture ratio and working concentration should be made before actual use.
●In case the adhesive solution in storage is in such conditions as white turbidity, translucent or obviously thickened, then it should no longer be used.
DELIVERY & STORAGE
●The products are inflammable, It is a must to transport and store as dangerous articles.
●It’s essential to take precautions against fire, heat , direct sun exposure or defected packaging during delivery or transportation. (The products must be handled with care in loading. )
●It’s essential to keep the product away from heat, fire, moisture and direct sun exposure. It should be stored in cool, dry, well-ventilated, indoor place (10-30)℃.
●It is prohibited to mix with water, alcohol, ammoniacal or other activated hydrogen liquid.
For further information, please consult our Technical support.
PACKAGING
| JT1150 Main agent | 20 kg/Bucket |
| GT1150 Curing agent | 3 kg/Bucket |
